mini 50 groups of CTCSS device TESUNHO Walkie Talkie 15km TH-850 uhf/vhf 5W two way radio

FOB Reference Price:Get Latest Price
$25.00 - $59.00 / Piece | 1 Piece/Pieces (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Fujian, China
Brand Name:
TESUNHO
Model Number:
TH-850PLUS
Type:
Handheld
Frequency Range:
136-174MHz/350-390MHz
Talk Range:
15KM
Storage Channel:
99
Dimensions:
120(W)mmx60(L)mmx40mm(D
CHARGER VOLTAGE:
110-220V
Operating Bandwidth:
±3.5kHz/3.75kHz
BATTERY CAPACITY:
3500MAH
FLASHLIGHT:
LED FLASHLIGHT
Weight(With Battery):
about 260g
Standby Current:
< 12mA
Max Freq Deviation:
< 5kHz(1000Hz When 100%)
RF Power Output:
0.5W/5W/10W
Audio Power Output:
500W When Distortion Less Than 10%
FM Noise:
30dB/40dB
Supply Ability
Supply Ability:
2000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
GIFT BOX/PC AND CUSTOMIZED CTN ACCORDING TO THE ORDER QUANTITY
Port
ShenZhen/XiaMen
Lead Time :
7 DAYS AFTER PAYMENT FOR BULK





mini 50 groups of CTCSS device TESUNHO Walkie Talkie 15km TH-850 uhf/vhf 5W  two way radio





0.5W/5W/10W

HI/LO power programmable

Noice suppression function

Voice function(Chinese/English),Voice ON/OFF

Hight power output(10W/9W)

Timer out timer;Monitor

Battery LED indicator

Rain-proof

Built-in Led flashlight

Battery save function

Low batter alarm(Voice prompt)

Keypad lock/unlock

Emergency alarm function(Local/Remote alarm)



50 groups of CTCSS

105 groups of DCS

3500mAh ultra high capacity Li-polymer rechargeable battery

Charging directly from the power supply or charging with the cradle.



Model NO.

TH-850

General

Frequency Band

VHF

UHF

Frequency Range

136-174MHz/350-390MHz

400-480MHz/440-520MHz

Channel Capacity

99

Operating Voltage

7.2V DC ±15%

Antenna Impedance

50Ω

Channel Spacing

12.5kHz/25kHz

Working Temperature

-30 °C - +60 °C

Frequency Stability

±2.5 ppm

Size (Without Antenna)

120(W)mmx60(L)mmx40mm(D)

Weight(With Battery)

about 260g

Battery

3500mAh(Li-poly battery)

Transmitter

RF Power Output

0.5W/5W/10W

Modulation Type

F3E

Modulation Distortion

< 5%(300-3000Hz)

Max Freq Deviation

< 5kHz(1000Hz When 100%)

FM Noise

<=-45dB

Receiver

Sensitivity(12Db SINAD)

0.16μV

Selectivity

55dB

Adjacent Channel Selecivity

>=70dB

Noise Respond

>=60dB

Communication Range

3-5km(Downtown),6-20km(In the Open Area)

FM Noise

30dB/40dB

Modulation Type

8K/16KF3E

Audio Power Output

500mW When Distortion Less Than 10%

Audio Distortion

< 5%

Operating Bandwidth

±3.5kHz/3.75kHz

Standby Current

< 12mA







Professional

10 years Electronics Design Experience.

Powerful and reliable R&D team.

Effective

Instant respond to customer's enquiry.

Control design and productive cost, cost-effective.

Trusted

Never reveal customers design.

Exclusivity is guaranteed!

To-be-perfectBecause of all the above.
Target Customer

Who has distinctive foresight on the industry.

Who wants to save the high expenses on R&D in order to enhance integrated competition.

Whole sellers who has a large local market and wants its own brand.

Warranty:



ItemPeriodService
Main Unit

 2 Years Warranty

finish maintainance within 1-15days

after receiving the returned units

BatteryHalf Year Warranty

Within Half Year:send you brand new one if it is not manually damaged;

Beyond Half Year:supply cost-effective renovation

ChargerHalf Year Warranty

Within Half Year:send you brand new one if it is not manually damaged;

Beyond Half Year:supply cost-effective renovation



Design Services:



ProjectDetailPrice
Circuit Board Designalso can produceNegotiable
programme Designalso can produceNegotiable
Repeater Designalso can produceNegotiable
Switch power supply Designalso can produceNegotiable
The transfer station Design           suitable for basement  Negotiable
